The Part Number package: 110 pcs in 1 tray, which is 34.5*34.5*27cm, 5.5KGS (550pcs) of each carton.
Product Display Gallery
Characteristics
RJ45 Connector with integrated transformer / common mode choke
Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s
Available in SMT, THT and THT with USB
Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEEE 802.3bt
HPLE products: Improved Common Mode Rejection due to additional NiZn cores
Production Profile & Overview
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE, and UL. The facility owns advanced manufacturing machinery and comprehensive testing equipments. Backed by abundant production capacities, we efficiently deliver standard and customized products within compressed timeframes. We provide comprehensive professional solutions for magnetic components alongside strong technical support. Our products are widely used in networking and communication equipments such as HUBs, PC cards, Switches, Routers, PC Mainboards, SDH, PDH, IP Phones, and xDSL modems.
Main Products:
10/100/1000M LAN pulse transformer and filter
RJ45 connector with 10/100/1000M magnetic
T1/E1, T3/DS3/E3/STS-1 interface line transformer
ISDN, HDSL, ADSL and VDSL interface line transformer and splitter
Our dedicated engineering staff focuses on identifying, developing, and manufacturing optimal solutions customized to meet unique specifications and requirements. We believe that our strong technical experience in this field and our commitment to quality assurance will help build valuable long-term partnerships.
Frequently Asked Questions (FAQ)
What are the primary applications for the LPJK9029A159NL RJ45 connector?
This connector is specifically designed for LAN applications, supporting high-speed 5G Base-T speeds and featuring AutoMDIX capabilities. It is widely used in network routers, switches, network hubs, and high-performance server network interface cards.
Is this RJ45 connector compliant with standard PoE requirements?
Yes, it features integrated characteristics designed to support Power over Ethernet (PoE) configurations up to 50 Watts. It complies with multiple IEEE standards, including IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, and upcoming IEEE 802.3bt.
What type of mounting orientation does this connector use?
This RJ45 connector is a through-hole type with a 90° angle (Right-Angle) orientation. It also includes board guide features to ensure precise positioning and mechanical stability during soldering.
What is the standard packaging details for shipment?
The standard tray packing holds 110 pieces per tray. Cartons measure 34.5*34.5*27cm, housing 550 pieces (5 trays) with a gross weight of approximately 5.5KGS per carton.
What are the environmental temperature limits for this part?
The LPJK9029A159NL operates reliably within a standard temperature range of 0°C to 70°C, making it ideal for indoor commercial and industrial networking applications.
How does the HPLE design improve signal performance?
High Performance Low Emission (HPLE) components utilize additional integrated NiZn cores. This addition provides significantly improved common-mode rejection, mitigating noise and ensuring reliable high-speed data transmission up to 10 Gbit/s.
