| Item | Fiber Optical Modules |
| Part Status | Active |
| Form Factor | QSFP-DD |
| Max Data Rate | 425Gbps (4x106.25Gb/s) |
| Max Cable Distance | 500m |
| Wavelength | 1310nm |
| Connector | MTP/MPO-12 APC |
| Media | SMF |
| Optical Component | DFB/PIN |
| TX Power | -2.9~4dBm |
| RX Power | -5.9~4.0dBm |
| Receiver Sensitivity | -6.5dBm |
| Powerbudget | 3dB |
| Power Consumption | ≤10W |
| Extinction Ratio | 3.5dB |
| DDM/DOM | DDM Supported |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Warranty | 5 Years |
| Sample | Available |
| Protocols | IEEE 802.3bs, QSFP-DD MSA, CMIS 4.1 |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE and UL. Our facilities own advanced manufacturing equipment and testing systems imported from industry-leading sources.
Established in 1997, our team has grown to around 2,000 professional staff. With an abundant monthly production capacity of 3,000K units, we ensure reliable delivery within highly efficient turnaround windows.
Furthermore, we provide a full series of optical modules designed for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also features high-speed optical interconnection solutions tailored for cloud computing and ultra-broadband networks. Leveraging the latest optoelectronics technologies, we design, produce, and supply products globally.
